Application
● USB3.0_Filter_C is designed for 5G Consumer Electronic devices for eliminating interference signals, It has high performance on RF isolation from 700MHz to 44GHz.
Electrical specification
Input Voltage | 20VDC |
Maximum Current | 3A |
Specification
Outer Dimension | 61(L) * 48.4(W) * 18.6(H)mm |
Installation Dimension | 25(W) * 12(H) mm |
Material | Aluminum alloy |
Color | Silver |
Product Net Weight | approx.0.3kg |
RF Isolation
● 700MHz~44GHz >70dB
